2.4 GHz: Yes
5 GHz: Yes
6 GHz: No
Antena: Interna
Antenna gain level (max): 5 dBi
Antenna type: Internal
Antennas quantity: 1
AP-Type: Managed
Band: N/A
Channel bandwidth: 160 MHz
Compatibil Mesh: N/A
Compliance certificates: CE, Federal Communications Commission (FCC), RoHS
DC voltage range: 12 V
DC-in jack: Yes
Depth: 188 mm
Dynamic Frequency Selection (DFS): Yes
Ethernet LAN (RJ-45) ports: 1
Ethernet LAN data rates: 10,100, 1000 Mbit/s
Firmware upgradeable: Yes
Flash memory: 8 MB
Frequency band: 2.4 - 5.85 GHz
Height: 37 mm
Input current: 1 A
Internal memory: 128 MB
IP address filtering: Yes
LED indicators: Yes
MAC address filtering: Yes
Maximum data transfer rate: 3000 Mbit/s
Maximum data transfer rate (2.4 GHz): 574 Mbit/s
Maximum data transfer rate (5 GHz): 2402 Mbit/s
Maximum indoor range: 15 m
MIMO: Yes
MIMO type: Multi User MIMO
Networking standards: IEEE 802.11n, IEEE 802.11a, IEEE 802.11ac, IEEE 802.3af, IEEE 802.11b, IEEE 802.11g
Numar porturi: 1-3
Operating modes: FIT AP, FAT AP
Operating relative humidity (H-H): 5 - 95%
Operating temperature (T-T): -20 - 45 °C
Package depth: 243 mm
Package height: 76 mm
Package weight: 890 g
Package width: 235 mm
Placement: Ceiling
PoE: Yes
Power consumption (max): 15 W
Power over Ethernet (PoE): Yes
Product colour: White
Quality of Service (QoS) support: Yes
Quantity per pack: 1 pc(s)
Reset button: Yes
Security algorithms: WPA-PSK, WPA2-PSK, WPA3-PSK
Service Set Identifier (SSID) features: Hidden SSID
Spread spectrum method: OFDMA
Storage temperature (T-T): -40 - 70 °C
Supported network protocols: UDP;IPv4;IP Filter;DNS;HTTP;PPPoE;NTP;DHCP;Qos;T CP/IP;DDNS;UPnP;ICMP
Sustainability compliance: Yes
Syslog: Yes
Tehnologie WI-FI: WiFi 6 - AX
Transmitting power (CE): 25 dBm
USB 2.0 ports quantity: 0
Viteza Transport: N/A
WAN connection: Ethernet (RJ-45)
Web-based management: Yes
Weight: 550 g
Width: 188 mm
WiFi-Frequency: 2.4/5-GHz
WiFi-Standard: ac


Denumiri similare la Access point Dahua EAP6230-C: EAP 6230 C, EAP6230C, EAP6230 C, EAP 6230-C
